Xilence 650W Gaming, ATX 2.52v 80+ GOLD, aktivan PFC, 3×PCIe, 6×SATA, 120mm ventilator, crno

XILENCE

Xilence 650W Gaming, ATX 2.52v 80+ GOLD, aktivan PFC, 3×PCIe, 6×SATA, 120mm ventilator, crno

88,73 €

Cijena uključuje PDV

Najniža cijena u zadnjih 30 dana: 88,73 €

Dostupno

Specifikacije

Whisper-quiet coolingLarge 120mm fan

Continuous power (W)650

Form factor ATX 12VVersion 2.52v

Voltage (Vac)200-240V

ModeGaming, XP650R12

Frequency (Hz)50Hz-60Hz

PFCactive

+3.3V (A)20

+5V (A)20

+12V1 (A)54.1

12V (A)0.3

+5Vsb (A)3

Max. combined power 12V (W)650

Max. combined power 3.3V + 5V (W)100

+12V2 (A)Yes

Bearing technologyHydro Bearing

Fan size (mm)120

OCP (over current protection)Yes

OVP (over voltage protection)Yes

UVP (under voltage protection)Yes

SCP (short circuit protection)Yes

OTP (over temperature protection)Yes

OPP (over power protection)Yes

80PLUS certificationmeet 80+ Gold

Efficiency (%) at 230V, 20% load90

Efficiency (%) at 230V, 50% load93

Efficiency (%) at 230V, 100% load92

ErPYes

WEEEYes

RoHSYes

Cable length to mainboard (mm)550

Cable length to first connector (mm)550

Maximum cable length (mm)600

Sleeved cablesYes

P4+4 (CPU)2

P8 (CPU)1

PCI-E 6+2-pin (GPU)3

SATA 15-pin (HDD, Drives)6

SKU: 61299

Opis proizvoda

- The Gaming GOLD Series is a PC power supply series with a fixed cable harness, as well as a 750W ARGB variant
- The noble design with its black powder coating, the 120mm silent, black or transparent fan and the fan grille emphasizes the valuable character of this series
- The maximum voltage stability and the six integrated safety circuits ensure safe operation even in heated workflows or gaming sessions
- The power supplies are suitable for the highest demands in gaming, multi-media application and streaming areas and have low power consumption during these intensive phases
- The power supplies achieve the 80+ GOLD requirements

Features
- Whisper-quiet cooling: Large 120mm fan*
- Excellent airflow design for improved heat dissipation
- With the following safety equipment:
* OVP (overvoltage protection)
* UVP (Undervoltage Protection)
* SCP (short circuit protection)
* OLP (overload protection)
* OTP (over temperature protection)
* OCP (overcurrent protection)
- Low standby power consumption
- High energy

Technical data
- Continuous power (W): 650
- Form factor ATX 12V: Version 2.52v
- Voltage (Vac): 200-240V
- Mode: Gaming | XP650R12
- Frequency (Hz): 50Hz-60Hz
- Input current (A) 6.3
- PFC: active

Output
* +3.3V (A): 20
* +5V (A) : 20
* +12V1 (A): 54.1
* -12V (A): 0.3
* +5Vsb (A): 3
* Max. combined power 12V (W): 650
* Max. combined power 3.3V + 5V (W): 100
* +12V2 (A): Yes

Fan / Cooling technology
- Bearing technology: Hydro Bearing
- Fan size (mm): 120

Protection
- OCP (over current protection): Yes
- OVP (over voltage protection): Yes
- UVP (under voltage protection): Yes
- SCP (short circuit protection): Yes
- OTP (over temperature protection): Yes
- OPP (over power protection): Yes

Eco / Efficiency
- 80PLUS certification: meet 80+ Gold
- Efficiency (%) at 230V, 20% load: 90
- Efficiency (%) at 230V, 50% load: 93
- Efficiency (%) at 230V, 100% load: 92

Environmental directives
- ErP: Yes
- WEEE: Yes
- RoHS: Yes

Cable management / Connectors
- Modular cable management: -
- Cable length to mainboard (mm): 550
- Cable length to first connector (mm): 550
- Maximum cable length (mm): 600
- Sleeved cables: Yes
- No. of cables: -
- ATX-Motherboard (20+4-pin): -
- P4+4 (CPU): 2
- P8 (CPU): 1
- PCI-E 6-pin (GPU): -
- PCI-E 6+2-pin (GPU): 3
- PATA 4-pin: -
- SATA 15-pin (HDD, Drives): 6
- FDD (Floppy): -
