TP-Link Omada JetStream 8-port Gigabit L2+ upravljiv preklopnik (Switch), 8×10/100/1000M RJ45 ports, VLAN, Desktop metalno kućište
Opis proizvoda
- Integrated into Omada SDN: Centralized Cloud Management, and Intelligent Monitoring
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management
- Robust Security Strategies: 802.1Q VLAN, ACL, Port Security, Storm Control, and more
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping
- Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features
Specifications
HARDWARE FEATURES
- Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
- Interface: 8× 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
- Network Media:
* 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
* 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
- Fan Quantity: Fanless
- Power Supply:
* 12 VDC/1 A External Adapter or
* Obtain Power from PoE Source
- Power Consumption: 6.4 W (220 V/50 Hz)
- Dimensions (W×D×H): 209×126×26 mm
PERFORMANCE
- Bandwidth/Backplane: 16 Gbps
- Packet Forwarding Rate: 11.9 Mpps
- MAC Address Table: 8K
- Jumbo Frame: 9 KB
SOFTWARE FEATURES
- Quality of Service:
* 802.1p CoS/DSCP priority
* 8 priority queues
* Priority Schedule Mode: SP (Strict Priority), WRR (Weighted Round Robin)
* Queue Weight Config
* Bandwidth Control: Port/Flow based Rating Limit
* Smoother Performance
* Storm Control: Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control
- L2 and L2+ Features:
* 16 IP Interfaces: Support IPv4/IPv6 Interface
* Static Routing: 32 IPv4/IPv6 Static Routes
* DHCP Server
* DHCP Relay: DHCP Interface Relay, DHCP VLAN Relay
* DHCP L2 Relay
* Static ARP
* Proxy ARP
* Gratuitous ARP
* Link Aggregation: Static link aggregation, 802.3ad LACP, Up to 8 aggregation groups and up to 8 ports per group
* Spanning Tree Protocol: 802.1D STP, 802.1w RSTP, 802.1s MSTP, STP Security: TC Protect, BPDU Filter/Protect, Root Protect
* Loopback Detection
* Flow Control: 802.3x Flow Control
* Mirroring: Port Mirroring, CPU Mirroring, One-to-One, Many-to-One, Flow-Based, Ingress/Egress/Both
* Device Link Detect Protocol (DLDP)
* 802.1ab LLDP/ LLDP-MED
- VLAN:
* VLAN Group: Max. 4K VLAN Groups
* 802.1Q tag VLAN
* MAC VLAN: 12 Entries
* Protocol VLAN
* GVRP
* Voice VLAN
- Access Control List:
* Support up to 230 entries
* Time-Range: Time Slice, Week Time-Range, Absolute Time-Range, Holiday
* Time-based ACL
* MAC ACL: Source MAC, Destination MAC, VLAN ID, User Priority, Ether Type
* IP ACL: Source IP, Destination IP, IP Protocol, TCP Flag, TCP/UDP Source Port, TCP/UDP Destination Port, DSCP/IP TOS
* IPv6 ACL
* Combined ACL
* Rule Operation: Permit/Deny
* Policy Action: Mirror, Rate Limit, Redirect, QoS Remark
* ACL Rules Binding: Port Binding, VLAN Binding
* Actions for flows: Mirror (to supported interface), Redirect (to supported interface), Rate Limit, QoS Remark
- Security:
* AAA
* 802.1X: Port based authentication, MAC (Host) based authentication, Authentication Method includes PAP/EAP-MD5, MAB, Guest VLAN, Support Radius authentication and accountability
* IP/IPv6-MAC Binding: 512 Binding Entries, DHCP Snooping, DHCPv6 Snooping, ARP Inspection, ND Detection
* IP Source Guard: 253 Entries, Source IP+Source MAC
* IPv6 Source Guard: 183 Entries, Source IPv6 Address+Source MAC
* DoS Defend
* Static/Dynamic/Permanent Port Security: Up to 64 MAC addresses per port
* Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode
* Port Isolation
* Secure web management through HTTPS with SSLv3/TLS 1.2
* Secure Command Line Interface (CLI) management with SSHv1/SSHv2
* IP/Port/MAC based access control
- Management:
* Web-based GUI
* Command Line Interface (CLI) through telnet
* SNMPv1/v2c/v3
* SNMP Trap/Inform
* RMON (1,2,3,9 groups)
* SDM Template
* DHCP/BOOTP Client
* Dual Image, Dual Configuration
* CPU Monitoring
* Cable Diagnostics
* EEE
* SNTP
* System Log
OTHERS
- Certification: CE, FCC, RoHS
- Package Contents: TL-SG2008, Power Adapter, Installation Guide, Rubber Feet
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
- Environment:
* Operating Temperature: 0C to 40C (32F to 104F)
* Storage Temperature: -40C to 70C (-40F to 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
